| Feeding system | Roller friction system |
| Display Screen | 4.3inch TFT touchscreen |
| Sorting function | Denomination Face / OrientationIssue versionholesInketc |
| Available Currencies | 140+kinds ofcurrencies |
| Denomination Detection | Contact Image Sensor |
| Reject capacity | 180pcs |
| Thickness of curencies | 0.08-0.15 mm |
| Power supply | 100-240V 50 /60 Hz |
| Dimension(L*W*H) | 260(L)*280 (VW)*275(H)mm |
| Package weight | 11.5kgs/unit |
| Machine Ports |
LAN (External dispaly connection) Type B USBport(PC connection) RS-232port(Printerconnection) / Type A USB2.0 port(data collection/machine update) |
| Counterfeit Detection | Roller friction system |
| Error Detection |
MagneticDetection Double Detection HalfNote Detection Chain Notes Detection |
| Add Mode | Allows acumulative counting |
| Courtingspeed | 800/1000/1200notes/min |
| Hopper capacity | 500pcs |
| Stackercapacity | 200pcs |
| Size of banknotes |
Minimum110*60mm Maximum185*90mm |
| Power Consumption | 170W |
| Net Weight | 9.5kg/unit |
| Options | External Display/Built-in printer |
TECHNICAL SPECIFICATION
